| Case Specification |
| Dimensions |
477 x 220 x 486 mm (DWH) |
| Form Factor |
Mid Tower |
| Materials |
Steel + Plastic |
| Mainboard Support |
ATX, M-ATX, ITX |
| Front Access & Controls |
Power, Fan Control Button, 2 x USB3.0, HD-AUDIO, 1 x USB 3.1 Gen 2 Type-C |
| Side Panel |
Steel Side Panel + sound dampening foam |
|
| Expansion & Drive Bays |
| Expansion Slots |
7 |
| 5.25" |
1 |
| 3.5" / 2.5" |
3 / 2 |
| 2.5" |
3 |
|
| Fan |
| Front |
3 x 120mm / 2 x 140mm |
| Power Supply Shroud |
2 x 120mm |
| Rear |
1 x 120mm |
| Included Fan(s) |
3 x 120mm fans in front & 1 x 120mm fan in rear |
|
| Radiator Support |
| Front |
120 / 240 / 280 / 360mm |
| Rear |
120mm |
|
| Clearance |
| Max GPU Length |
≤ 405mm |
| Max CPU Cooler Height |
≤ 175mm |
| Max PSU Length |
≤ 205mm |
|
| Miscellaneous |
| Dust Filter |
Front / Bottom |
| Net Weight |
7.7kg |
| Gross Weight |
9kg |
| Warranty |
2 years |
| UPC# |
0-761345-80102-7 |
|
|
ABKO Suitmaster 322S White Tempered Glass ATX Computer Case
Product Description
- Middle tower / ATX, M-ATX, Mini ITX / Standard installed cooling fan: 4 / Graphics card installation (maximum): 380mm / CPU cooler installation (maximum): 175mm / Water cooling radiator support: 240mm (120mm x 2), 280mm (140mm x 2), 360mm (120mm x 3) / Additional features: side window, tempered glass, fan controller, built-in LED fan, dust filter, ODD cannot be installed / 3.5 inches (HDD): 2 or less / 2.5 inches (SSD) ): 4 or more / Front ports: USB 2.0, USB 3.0, AUDIO, LED control / Power included: Power not included (separately)
|
| Case Specification |
| Dimensions |
420 x 210 x 402mm (LxWxH) |
| Form Factor |
Mini Tower |
| Materials |
SPCC & Plastic |
| Mainboard Support |
Micro-ATX、Mini-ITX |
| Front Access & Controls |
USB3.0 x 2, MIC/AUDIO(HD), Power, Reset, Mode |
| Side Panel |
Tempered Glass Side Panel |
|
| Expansion & Drive Bays |
| Expansion Slots |
4 |
| 5.25" |
0 |
| 3.5"/2.5" (convertible) |
2 |
| 2.5" |
2 |
|
| Cooling |
| Front |
3 x 120mm / 2 x 140mm |
| Top |
2 x 120mm / 2 x 140mm |
| Rear |
1 x 120mm |
| Included Fan(s) |
1 x 120mm in rear |
|
| Radiator Support |
| Front |
≤ 280mm |
| Rear |
≤ 120mm |
|
| Clearance |
| Max GPU Length |
≤ 360mm |
| Max CPU Height |
≤ 160mm |
| Max PSU Length |
≤ 170mm |
|
| Others |
| Dust Filters |
Top / Bottom |
| Net Weight |
4.9 kgs |
| Gross Weight |
5.9 kgs |
| UPC# |
0-761345-80020-4 |
| Package Dimension |
455 x 260 x 485 mm (DWH) |
| Warranty |
2 Years |
|
|
.jpg)
|
| Case Specification |
| Dimensions |
351 x 200 x 390mm (D x W x H)
364 x 212 x 396 (D x W x H) (With handle) |
| Form Factor |
Mini Tower |
| Materials |
Steel + Plastic |
| Mainboard Support |
M-ATX, ITX |
| Front Access & Controls |
Power, Reset, 1 x USB3.0, 2 x USB2.0 , MIC/HD-AUDIO |
| Side Panel |
Tempered Glass Side Panel |
|
| Expansion & Drive Bays |
| Expansion Slots |
4 |
| 3.5" /2.5" |
2 / 1 |
| 2.5" |
1 |
|
| Fan Support |
| Front |
2 x 120mm / 2 x 140mm |
| Top |
2 x 120mm |
| Rear |
1 x 120mm |
| Included Fan(s) |
1 x 120mm fan in rear |
|
| Radiator Support |
| Front |
120 / 140 / 240mm |
| Rear |
120mm |
|
| Clearance |
| Max GPU Length |
≤ 275mm |
| Max CPU Cooler Height |
≤ 150mm |
| Max PSU Length |
≤ 150mm |
|
| Miscellaneous |
| Dust Filter |
Bottom |
| Net Weight |
3.51KG |
| Gross Weight |
4.34KG |
| Warratny |
1 year |
| UPC# |
0-761345-81049-4 |
|
|
| Case Specification |
| Dimensions |
469 x 220 x 490mm (DWH) |
| Form Factor |
Mid Tower |
| Materials |
Steel + Plastic |
| Mainboard Support |
E-ATX, ATX, Micro-ATX, ITX |
| Front Access & Controls |
Power, Reset , USB 3.0 x 2, Type-C 3.2 Gen 2 x 1, MIC x 1, HD-AUDIO x 1 |
| Side Panel |
4 MM Tempered Glass Side Panel |
|
| Drive Bays |
| Expansion Slots |
7 |
| 3.5" / 2.5" |
2 / 2 |
| 2.5" |
2 |
|
| Fan |
| Front |
3 x 120mm / 3 X 140mm / 2 x 185mm |
| Top |
3 x 120mm / 2 x 140mm |
| Power Supply Shroud |
2 x 120mm |
| Rear |
1 x 120mm |
| Included Fan(s) |
3 x 120mm PWM fans in front |
|
| Radiator Support |
| Front |
120 / 140 / 240 / 280 / 360mm |
| Top |
120 / 140 / 240 / 280 / 360mm |
| Rear |
120mm |
|
| Clearance |
| Max GPU Length |
≤ 375mm |
| Max CPU Cooler Height |
≤ 170mm |
| Max PSU Length |
(Include cable) ≤ 205mm(with HDD)
(Include cable) ≤ 410mm(without HDD) |
|
| Miscellaneous |
| Dust Filter |
Front / Top / Bottom |
| Net Weight |
8.1 Kgs |
| Gross Weight |
9.32 Kgs |
| Warranty |
2 Years |
| UPC# |
0-761345-80103-4 |
|
|
